TRAXXAS Bigfoot No. 1 Electric 2WD Monster Truck 1/10 RTR
The
2024 BIGFOOT is here! Now featuring heavily reinforced heavy-duty
suspension and drivetrain components, plus clipless body assembly.
Experience increased durability, efficiency, and pure driving fun.
The
BIGFOOT is THE original monster truck. It started the monster truck and
car-smashing action at fairs and stadiums. This new, fully licensed,
and highly detailed replica embodies the spirit of the legendary monster
truck, and you'll feel like you're reliving your first monster truck
experience.
It shimmers in metallic blue. The attached
chrome-plated plastic parts, like the elaborate grille and KC light bar,
shine like they're under arena lights. For BIGFOOT fans, it's simply a
must-have and won't disappoint!
Features
• Licensed Replica Bigfoot Body
• Clipless Body Mounting
• Extreme Heavy-Duty Suspension and Drivetrain Components
• Torsionally Rigid Composite Chassis
• Torque-Control™ Slipper System
• Ultra Oil-Filled Shocks
• Titan 12-Turn 550 Motor
• Waterproof XL-5 ESC
• Waterproof High-Torque 2056 Servo
• TQ 2.4GHz 2-Channel Radio System
• Terra-Groove Tires on 2.2" Chrome Wheels
• Powerful Traxxas 3000mAh 8.4V NiMH Battery with iD Connector
• 4 Amp USB-C Fast Charger
• Top Speed of Up to 50 km/h (with 8.4V and included 19T pinion gear)
The
Bigfoot is based on the technology of the popular Stampede, but it is a
licensed, true-to-life replica of the legendary Bigfoot. Monster trucks
and is also equipped with the typical tires.
The Stampede was
the first high-performance monster truck and has become synonymous with
action and driving fun. Its appealing design, innovative features, and
even more power make it what it is today. The combination of power,
off-road agility, waterproof electronics, and ease of use puts it at the
top of the monster truck category.
Changing batteries is quick
and easy thanks to a special battery holder. The pre-installed bevel
gear differential is perfectly tuned and maintenance-free. Just take the
Bigfoot out of the box, charge it, and you're ready to tear through the
terrain and do wheelies.
TQ 2.4GHz 2-Channel Radio System
With
the included 2.4GHz radio system, you don't need to set any channels or
frequencies. The ergonomic design, with its integrated and therefore
protected antenna, is very appealing. The TQ is lightweight and fits
comfortably in your hand.
Traxxas 7-Cell 8.4-Volt NiMH Battery
Included
is a powerful 7-cell battery. 8.4-volt NiMH battery with foil-wrapped
cells, flexible silicone cables, and gold-plated connectors. The iD
connector, when used with the Traxxas iD charger (sold separately),
provides unique battery protection by automatically detecting the
battery type and adjusting the charging process accordingly. The
included battery can be easily replaced with other NiMH batteries or
LiPo batteries offering higher performance and longer run times.
Waterproof Electronics
The
12T 550 modified motor with built-in cooling fan is built to last. The
XL-5 ESC offers three driving profiles and is easy to use with the
one-button EZ-Set system. The ESC and receiver box are sealed, allowing
for driving through water, mud, and snow.
The exclusive, patented
Training Mode limits power to 50% at the touch of a button, making it
ideal for young drivers or beginners.
Specifications:
• Length: 413 mm
• Width: 324 mm
• Height: 241 mm
• Wheelbase: 270mm
• Tire size: 2.2"
• Gear ratio: 48dp
• Gear ratio: 12.34:1
• Battery size: 164x46x26mm
• Weight: 1.85kg
Required accessories:
• 4x AA batteries for transmitter
MODEL SPECS
| Name: |
BIGFOOT No 1 HD w/USB-C |
| Type: |
Monster Truck |
| Speed: |
30+ mph with 7-cell battery |
| Skill Level: |
1 |
| Scale: |
1/10 |
| Weight: |
4.08 pounds (1.85 kg) |
| Length: |
16.25 inches (413 mm) |
| Width: |
12.75 inches (324 mm) |
| Front Track: |
12.75 inches (324 mm) |
| Rear Track: |
12.75 inches (324 mm) |
| Height: |
9.5 inches (241 mm) |
| Wheelbase: |
10.63 inches (270 mm) |
| Center Ground Clearance: |
4 inches (102 mm) |
| Driveline: |
2WD |
| Transmission: |
Magnum 272™ |
| Differential Type: |
Planetary steel gear |
| Gear Ratio (Internal): |
2.72 (final drive: 12.34) |
| Gear Pitch: |
48 pitch |
| Steering Servo: |
2056 high-torque waterproof |
| Radio System: |
TQ™ 2.4 GHz 2-channel radio |
| Battery Compartment Specs: |
164 mm X 46 mm X 26 mm |
MOTOR SPECS
| Name: |
Titan® 12T 550 |
| Type: |
High-speed brushed motor |
| Weight: |
8.47 ounces (240 g) |
| Length: |
3.07 inches (78 mm) overall length, 2.25 inches (57 mm) can length |
| Diameter: |
1.41 inches (36 mm) |
| Shaft Size: |
3 mm |
| Connector Type: |
Bullet |
ESC SPECS
| Name: |
Waterproof XL-5™ ESC with low-voltage detection |
| Type: |
Brushed |
| Case Size: |
1.23 inches (31 mm) / 2.18 inches (55 mm) / 1.04 inches (26 mm) |
| Weight: |
2.44 ounces (69 g) |
| Motor Connectors: |
Bullet |
| Battery Connectors: |
Traxxas High-Current Connector |
| Power Wire: |
14 gauge |
